Users may find here below certain limitations of the “Explode” commands. The command opens each Advance Steel drawing, performs the exploding and then automatically closes it.
How to explode a block in autocad 2019 how to#
DWG files and finally click OK.įigure 4 – How to use the “ Explode drawings” command Select the desired registered drawings, click on the Explode button in the dialog window, choose where to save the exploded. Similarly, for a set of generated details drawings, open the Advance Steel model and use the “Explode drawings ” command. The resulting exploded drawing contains AutoCAD dimension lines, which can be further edited:įigure 3 – Result of the “Explode” commands: AutoCAD dimensions Choose where to save the exploded details drawing and click OK.įigure 2 – How to use the “Explode details” commandĪfter performing the exploding, the command automatically closes the Advance Steel drawing and opens the exploded one. DWG format by exploding either a single drawing ( “Explode details” command), or a set of drawings ( “Explode drawings” command), whilst having the advantage of obtaining AutoCAD dimension lines, which can be further edited and controlled in an easy manner.įor a single drawing, use the “ Explode details ” command and click on the Explode button in the dialog window. The user can choose to convert Advance Steel-generated details drawings to. I feel better to disable block exploding.A set of powerful tools available in the PowerPack for Advance Steelextension are the “Explode details” and “Explode drawings” commands:įigure 1 – “Explode” commands in Power Pack for Advance Steel Sure, many AutoCAD users know how to enable block exploding.īut in my experience, if we are familiar with block, we will modify block using Block Editor or Edit Block In-Place. This option is great to prevent block from being exploded by accident. It’s under Block category.Īfter you changed the property, click Close Block Editor.īlock Editor will ask you to save or discard the changes. Press Ctrl+1 to open it.įind Allow Exploding option in this palette. In Block Editor, open Properties Palette. Choose Block Editor from context menu.Īlternatively you can type BEDIT then enter to select block name from list. Select the block you want to explode, click your mouse right button. The question is, what if the block is already created with “Allow exploding” option unchecked? How can we change this option? To allow the block being exploded, you should know now that we need to check the same option.
With the option unchecked, when you try to explode the block you will see this notification on command line. When you create a block, just uncheck “Allow Exploding” option.
It’s easy to prevent people from exploding block accidentally. You can protect your block from being exploded accidentally! Prevent Exploding Block It is very annoying if it was a dynamic block or blocks with attributes.ĪutoCAD block has an option to prevent this from happening. And sometimes people just don’t know how to work with blocks and explode it. Do you use AutoCAD block? I found it annoying when other people work on my drawing and explode my blocks.
